Apparent Density: 2.10~2.30g/cm3
Hardness: Shore D 60-65
Pressure Resistance: Up To 15 MPa
Thickness: Customizable (e.g., 1mm, 2mm)
Recovery Rate: ≥ 50%
Tensile Strength: ≥15MPa
HS Code: 39209910
Production Capacity: 500000 pieces/Month
PTFE Gaskets are high-performance sealing materials made from expanded polytetrafluoroethylene (ePTFE), offering exceptional flexibility and sealing capabilities. Their unique microporous structure enables superior sealing under low stress while maintaining high chemical and temperature resistance. Suitable for extreme temperature environments, ePTFE gaskets operate from -240°C to +260°C and resist corrosion from most acids, alkalis, and solvents. Additionally, their low density (0.4-0.8 g/cm³) and lightweight design make them ideal for various industrial applications.
Expanded PTFE Gaskets feature excellent compressibility and recovery rates, with compression rates of 20-40% and recovery rates exceeding 50%, ensuring stable sealing performance even after repeated compression. Their thickness can be customized, typically ranging from 1mm to 3mm, making them suitable for sealing flanges and joints. Expanded PTFE Gaskets are widely used in chemical, pharmaceutical, food processing, and semiconductor industries, particularly in applications requiring high cleanliness and corrosion resistance. Their white color and smooth surface also make them a preferred choice for food-grade applications.
As a versatile sealing solution, Expanded PTFE Gaskets not only provide exceptional sealing performance but also offer excellent aging resistance and durability. Their low friction coefficient and self-lubricating properties reduce installation and maintenance challenges while extending service life. Whether used for static or dynamic sealing, ePTFE gaskets deliver reliable performance to meet demanding industrial requirements. Their eco-friendly and recyclable nature also aligns with modern sustainability goals.
| Outside Diameter | Inside Diameter | Thickness | |||
| 1-7/8”(48mm) | 1/2”(12.7mm) | 0.04”(1.02mm) 1/15”(1.6mm) 3/16”(4.8mm) 1/4”(6.4mm) | |||
| 2-1/4”(57mm) | 3/4”(19mm) | ||||
| 2-5/8”(67mm) | 1”(25.4mm) | ||||
| 3-3/8”(86mm) | 1-1/2”(38mm) | ||||
| 4-1/8”(105mm) | 2”(51mm) | ||||
| 5-3/8”(136.5mm) | 3”(76mm) | ||||
| 6-7/8”(175mm) | 4”(102mm) | ||||
| 8-3/4”(222mm) | 6”(152mm) | ||||
| 11”(279mm) | 8”(203mm) | ||||
